Specifications
5 configurations
| LED quantity / Strip type | Power | PCB width | Voltage → Cut length | More specifications | Select for quote |
|---|---|---|---|---|---|
| 384 LEDLong-run / high-efficacyWS-COB-08-001 | 10 W/m ±10% | 8 mm | 24 V → 31.25 mm |
More specifications
| Long-Run COB LED Strips; Model WS-COB-08-001; Long-run / high-efficacy; 384 LED; 10 W/m ±10%; PCB options 8 mm; Supply / cut options: 24 V → 31.25 mm cut; Efficacy: ≥90 lm/W (±10%); Construction: No Voltage Drop; Colors / CCT: 3000K ±150K / 4000K ±150K / 6000K ±150K; CRI: ≥90; Roll length: 10 m
|
| 384 LEDLong-run / high-efficacyWS-COB-08-001 | 10 W/m ±10% | 8 mm | 24 V → 31.25 mm |
More specifications
| Long-Run COB LED Strips; Model WS-COB-08-001; Long-run / high-efficacy; 384 LED; 10 W/m ±10%; PCB options 8 mm; Supply / cut options: 24 V → 31.25 mm cut; Efficacy: >80 lm/W (±10%); Construction: 15m No Voltage Drop; Colors / CCT: 2600K-2800K / 2800K-3200K / 3850K-4250K / 6100K-6600K; CRI: ≥90; Roll length: 15 m
|
| 384 LEDLong-run / high-efficacyWS-COB-08-001 | 10 W/m ±10% | 8 mm | 24 V → 31.25 mm |
More specifications
| Long-Run COB LED Strips; Model WS-COB-08-001; Long-run / high-efficacy; 384 LED; 10 W/m ±10%; PCB options 8 mm; Supply / cut options: 24 V → 31.25 mm cut; Efficacy: ≥90 lm/W (±10%); Construction: 20m No Voltage Drop; Colors / CCT: 2700K ±150K / 3000K ±150K / 4000K ±150K / 6000K ±150K; CRI: ≥90; Roll length: 20 m
|
| 480 LEDLong-run / high-efficacyWS-COB-02-001 | 14.5 W/m ±10% | 10 mm | 24 V → 50 mm |
More specifications
| Long-Run COB LED Strips; Model WS-COB-02-001; Long-run / high-efficacy; 480 LED; 14.5 W/m ±10%; PCB options 10 mm; Supply / cut options: 24 V → 50 mm cut; Efficacy: >140 lm/W (±10%); Colors / CCT: 2600K-2800K / 2900K-3200K / 3900K-4300K / 6000K-6500K; CRI: ≥90; Roll length: 10 m
|
| 480 LEDLong-run / high-efficacyWS-COB-08-002 | 7.5 W/m ±10% | 8 mm | 24 V → 50 mm |
More specifications
| Long-Run COB LED Strips; Model WS-COB-08-002; Long-run / high-efficacy; 480 LED; 7.5 W/m ±10%; PCB options 8 mm; Supply / cut options: 24 V → 50 mm cut; Efficacy: >100 lm/W (±10%); Construction: Constant Current; Colors / CCT: 2600K-2800K / 2900K-3200K / 3900K-4300K / 6000K-6500K; CRI: ≥90; Roll length: 20 m
|
