Multi-Row COB LED Strips
- PCB widths
- 12 / 15 / 30 mm
- Voltage options
- 24 V
Specifications
4 configurations
| LED quantity / Strip type | Power | PCB width | Voltage → Cut length | More specifications | Select for quote |
|---|---|---|---|---|---|
| 600 LEDDouble rowWS-COB-08-003 | 24 W/m ±10% | 12 mm | 24 V → 20 mm |
More specifications
| Multi-Row COB LED Strips; Model WS-COB-08-003; Double row; 600 LED; 24 W/m ±10%; PCB options 12 mm; Supply / cut options: 24 V → 20 mm cut; Efficacy: >80 lm/W (±10%); Construction: Double row; Colors / CCT: 2600K-2800K / 2800K-3200K / 3850K-4250K / 6100K-6600K; CRI: ≥90; Roll length: 5 m
|
| 960 LEDDouble rowWS-COB-08-003 | 28 W/m ±10% | 12 mm | 24 V → 33.3 mm |
More specifications
| Multi-Row COB LED Strips; Model WS-COB-08-003; Double row; 960 LED; 28 W/m ±10%; PCB options 12 mm; Supply / cut options: 24 V → 33.3 mm cut; Efficacy: >90 lm/W (±10%); Construction: Double row; Colors / CCT: 2600K-2800K / 2800K-3200K / 3850K-4250K / 6100K-6600K; CRI: ≥90; Roll length: 5 m
|
| 960 LEDTriple rowWS-COB-08-004 | 25 W/m ±10% | 15 mm | 24 V → 50 mm |
More specifications
| Multi-Row COB LED Strips; Model WS-COB-08-004; Triple row; 960 LED; 25 W/m ±10%; PCB options 15 mm; Supply / cut options: 24 V → 50 mm cut; Efficacy: >90 lm/W (±10%); Construction: Triple row; Colors / CCT: 2800K-3200K / 3850K-4250K / 6100K-6600K; CRI: ≥90; Roll length: 5 m
|
| 1600 LEDFive rowsWS-COB-08-005 | 40 W/m ±10% | 30 mm | 24 V → 25 mm |
More specifications
| Multi-Row COB LED Strips; Model WS-COB-08-005; Five rows; 1600 LED; 40 W/m ±10%; PCB options 30 mm; Supply / cut options: 24 V → 25 mm cut; Efficacy: >90 lm/W (±10%); Construction: Five rows; Colors / CCT: 2800K-3200K / 3850K-4250K / 6100K-6600K; CRI: ≥90; Roll length: 5 m
|
