SMD LED Strip Catalog V7
Full catalog · p. 29
Download PDF ↓
No image for this option.
Specifications
Operating-temperature rating is not specified.
14 configurations
| LEDs / Strip type | Power | PCB width | Voltage → Cut length | More specifications | Select for quote |
|---|---|---|---|---|---|
| 120 LEDs/m2835 · High-temperature PCBWS-SMD-07-035 | 11 W/m | 5 (unit not specified) | 24 V DC → Free cut | More specifications
| 2835 High-Temperature and Plated-PCB LED Strips; Model WS-SMD-07-035; 2835; High-temperature PCB; 120 LEDs/m; 11 W/m; Supply / cut options: 24 V DC → Free cut; Colors / CCT: White / Warm / Natural; CRI: 80; PCB: 5; Luminous flux: 24-26 lm/LED; IP rating: IP20; Copper: 18/50 copper; Maximum run: 10 m
|
| 120 LEDs/m2835 · High-temperature PCBWS-SMD-07-036 | 11 W/m | 8 (unit not specified) | 24 V DC → Free cut | More specifications
| 2835 High-Temperature and Plated-PCB LED Strips; Model WS-SMD-07-036; 2835; High-temperature PCB; 120 LEDs/m; 11 W/m; Supply / cut options: 24 V DC → Free cut; Colors / CCT: White / Warm / Natural; CRI: 80; PCB: 8; Luminous flux: 24-26 lm/LED; IP rating: IP20; Copper: 18/50 copper; Maximum run: 10 m
|
| 120 LEDs/m2835 · High-temperature PCBWS-SMD-07-049 | 11 W/m | 8 (unit not specified) | 24 V DC | More specifications
| 2835 High-Temperature and Plated-PCB LED Strips; Model WS-SMD-07-049; 2835; High-temperature PCB; 120 LEDs/m; 11 W/m; Supply / cut options: 24 V DC; Colors / CCT: White / Warm / Natural; PCB: 8; Luminous flux: 24-26 lm; IP rating: IP20; Copper: 18/50 copper; Maximum run: 10 m
|
| 120 LEDs/m2835 · High-temperature PCBWS-SMD-07-053 | 11 W/m | 5 (unit not specified) | 24 V DC | More specifications
| 2835 High-Temperature and Plated-PCB LED Strips; Model WS-SMD-07-053; 2835; High-temperature PCB; 120 LEDs/m; 11 W/m; Supply / cut options: 24 V DC; Colors / CCT: White / Warm / Natural; PCB: 5; Luminous flux: 24-26 lm/LED; IP rating: IP20; Copper: 18/50 copper; Maximum run: 10 m
|
| 120 LEDs/m2835 · High-temperature PCBWS-SMD-07-054 | 11 W/m | 8 (unit not specified) | 24 V DC | More specifications
| 2835 High-Temperature and Plated-PCB LED Strips; Model WS-SMD-07-054; 2835; High-temperature PCB; 120 LEDs/m; 11 W/m; Supply / cut options: 24 V DC; Colors / CCT: White / Warm / Natural; CRI: 80; PCB: 8; Luminous flux: 26-28 lm/LED; IP rating: IP20; Copper: 18/50 copper; Maximum run: 10 m
|
| 120 LEDs/m2835 · High-temperature PCBWS-SMD-07-059 | 6 W/m | 8 (unit not specified) | 24 V DC | More specifications
| 2835 High-Temperature and Plated-PCB LED Strips; Model WS-SMD-07-059; 2835; High-temperature PCB; 120 LEDs/m; 6 W/m; Supply / cut options: 24 V DC; Colors / CCT: White / Warm / Natural; PCB: 8; Luminous flux: 24-26 lm; IP rating: IP20; Copper: 18/50 copper; Maximum run: 20 m
|
| 120 LEDs/m2835 · Plated PCBWS-SMD-07-037 | 11 W/m | 5 (unit not specified) | 24 V DC → Free cut | More specifications
| 2835 High-Temperature and Plated-PCB LED Strips; Model WS-SMD-07-037; 2835; Plated PCB; 120 LEDs/m; 11 W/m; Supply / cut options: 24 V DC → Free cut; Colors / CCT: White / Warm / Natural; CRI: 80; PCB: 5; Luminous flux: 24-26 lm/LED; IP rating: IP20; Copper: 18/50 copper; Maximum run: 10 m
|
| 120 LEDs/m2835 · Plated PCBWS-SMD-07-038 | 11 W/m | 8 (unit not specified) | 24 V DC → Free cut | More specifications
| 2835 High-Temperature and Plated-PCB LED Strips; Model WS-SMD-07-038; 2835; Plated PCB; 120 LEDs/m; 11 W/m; Supply / cut options: 24 V DC → Free cut; Colors / CCT: White / Warm / Natural; CRI: 80; PCB: 8; Luminous flux: 24-26 lm/LED; IP rating: IP20; Copper: 18/50 copper; Maximum run: 10 m
|
| 120 LEDs/m2835 · Plated PCBWS-SMD-07-050 | 11 W/m | 5 (unit not specified) | 12 V DC24 V DC | More specifications
| 2835 High-Temperature and Plated-PCB LED Strips; Model WS-SMD-07-050; 2835; Plated PCB; 120 LEDs/m; 11 W/m; Supply / cut options: 12 V DC; Colors / CCT: White/Warm/Natural + extended colors; PCB: 5; Luminous flux: 24-26 lm/LED; IP rating: IP20; Copper: 25/25 copper; Maximum run: 10 m2835 High-Temperature and Plated-PCB LED Strips; Model WS-SMD-07-050; 2835; Plated PCB; 120 LEDs/m; 11 W/m; Supply / cut options: 24 V DC; Colors / CCT: White/Warm/Natural + extended colors; PCB: 5; Luminous flux: 24-26 lm/LED; IP rating: IP20; Copper: 25/25 copper; Maximum run: 10 m
|
| 180 LEDs/m2835 · Plated PCBWS-SMD-07-051 | 15 W/m | 5 (unit not specified) | 12 V DC24 V DC | More specifications
| 2835 High-Temperature and Plated-PCB LED Strips; Model WS-SMD-07-051; 2835; Plated PCB; 180 LEDs/m; 15 W/m; Supply / cut options: 12 V DC; Colors / CCT: White / Warm / Natural; PCB: 5; Luminous flux: 24-26 lm/LED; IP rating: IP20; Copper: 2 oz copper; Maximum run: 10 m2835 High-Temperature and Plated-PCB LED Strips; Model WS-SMD-07-051; 2835; Plated PCB; 180 LEDs/m; 15 W/m; Supply / cut options: 24 V DC; Colors / CCT: White / Warm / Natural; PCB: 5; Luminous flux: 24-26 lm/LED; IP rating: IP20; Copper: 2 oz copper; Maximum run: 10 m
|
| 180 LEDs/m2835 · Plated PCBWS-SMD-07-052 | 15 W/m | 3 (unit not specified) | 12 V DC24 V DC | More specifications
| 2835 High-Temperature and Plated-PCB LED Strips; Model WS-SMD-07-052; 2835; Plated PCB; 180 LEDs/m; 15 W/m; Supply / cut options: 12 V DC; Colors / CCT: White / Warm / Natural; PCB: 3; Luminous flux: 24-26 lm/LED; IP rating: IP20; Copper: 2 oz copper; Maximum run: 10 m2835 High-Temperature and Plated-PCB LED Strips; Model WS-SMD-07-052; 2835; Plated PCB; 180 LEDs/m; 15 W/m; Supply / cut options: 24 V DC; Colors / CCT: White / Warm / Natural; PCB: 3; Luminous flux: 24-26 lm/LED; IP rating: IP20; Copper: 2 oz copper; Maximum run: 10 m
|
| 180 LEDs/m2835 · Plated PCBWS-SMD-07-055 | 15 W/m | 8 (unit not specified) | 24 V DC | More specifications
| 2835 High-Temperature and Plated-PCB LED Strips; Model WS-SMD-07-055; 2835; Plated PCB; 180 LEDs/m; 15 W/m; Supply / cut options: 24 V DC; Colors / CCT: White / Warm / Natural; PCB: 8; Luminous flux: 24-26 lm/LED; IP rating: IP20; Copper: 25/25 copper; Maximum run: 10 m
|
| 240 LEDs/m2835 · Plated PCBWS-SMD-07-056 | 18 W/m | 10 (unit not specified) | 24 V DC | More specifications
| 2835 High-Temperature and Plated-PCB LED Strips; Model WS-SMD-07-056; 2835; Plated PCB; 240 LEDs/m; 18 W/m; Supply / cut options: 24 V DC; Colors / CCT: White / Warm / Natural; PCB: 10; Luminous flux: 24-26 lm/LED; IP rating: IP20; Copper: 25/25 copper; Maximum run: 10 m
|
| 120 LEDs/m2835 · Plated PCBWS-SMD-07-060 | 6 W/m | 8 (unit not specified) | 24 V DC | More specifications
| 2835 High-Temperature and Plated-PCB LED Strips; Model WS-SMD-07-060; 2835; Plated PCB; 120 LEDs/m; 6 W/m; Supply / cut options: 24 V DC; Colors / CCT: White / Warm / Natural; CRI: 80; PCB: 8; Luminous flux: 24-26 lm/LED; IP rating: IP20; Copper: 25/50 copper; Maximum run: 20 m
|
No matching options. Reset filters to try again.
Not all options can be combined.
Downloads
No document for this option.
Request a quote
Selected option
No option selected.
