Tunable White COB LED Strips
- Wiring
- 2-wire / 3-wire
- Voltage options
- 5 V / 12 V / 24 V
Specifications
15 configurations
| LED quantity / Strip type | Power | PCB width | Voltage → Cut length | More specifications | Select for quote |
|---|---|---|---|---|---|
| 480 LED2-wire CCTWS-COB-05-005 | 7+7 W/m ±10% | 6.6 mm | 12 V → 12.5 mm |
More specifications
| Tunable White COB LED Strips; Model WS-COB-05-005; 2-wire CCT; 480 LED; 7+7 W/m ±10%; PCB options 6.6 mm; Supply / cut options: 12 V → 12.5 mm cut; Construction: Solderless / pre-tinned PCB; Colors / CCT: 2700K ±150K / 6500K ±250K; Roll length: 5 m
|
| 576 LED2-wire CCTWS-COB-05-003 | 10+10 W/m ±10% | 8 mm | 24 V → 41.66 mm |
More specifications
| Tunable White COB LED Strips; Model WS-COB-05-003; 2-wire CCT; 576 LED; 10+10 W/m ±10%; PCB options 8 mm; Supply / cut options: 24 V → 41.66 mm cut; Construction: Dam encapsulation; Colors / CCT: 2600K–2800K / 6000K–6500K; Roll length: 10 m
|
| 600 LED2-wire CCTWS-COB-05-001 | 7+7 W/m ±10% | 5 mm | 12 V → 10 mm |
More specifications
| Tunable White COB LED Strips; Model WS-COB-05-001; 2-wire CCT; 600 LED; 7+7 W/m ±10%; PCB options 5 mm; Supply / cut options: 12 V → 10 mm cut; Colors / CCT: 2700K / 6500K; Roll length: 5 m
|
| 600 LED2-wire CCTWS-COB-05-001 | 7+7 W/m ±10% | 5 mm | 24 V → 20 mm |
More specifications
| Tunable White COB LED Strips; Model WS-COB-05-001; 2-wire CCT; 600 LED; 7+7 W/m ±10%; PCB options 5 mm; Supply / cut options: 24 V → 20 mm cut; Colors / CCT: 2700K / 6500K; Roll length: 5 m
|
| 600 LED2-wire CCTWS-COB-05-002 | 7+7 W/m ±10% | 8 mm | 24 V → 20 mm |
More specifications
| Tunable White COB LED Strips; Model WS-COB-05-002; 2-wire CCT; 600 LED; 7+7 W/m ±10%; PCB options 8 mm; Supply / cut options: 24 V → 20 mm cut; Colors / CCT: CCT; Roll length: 5 m
|
| 576 LED3-wire CCTWS-COB-05-009 | 10+10 W/m ±10% | 8 mm | 24 V → 41.66 mm |
More specifications
| Tunable White COB LED Strips; Model WS-COB-05-009; 3-wire CCT; 576 LED; 10+10 W/m ±10%; PCB options 8 mm; Supply / cut options: 24 V → 41.66 mm cut; Construction: Dam encapsulation; Colors / CCT: 2600–6500K; Roll length: 10 m
|
| 608 LED3-wire CCTWS-COB-05-007 | 6+6 W/m ±10% | 5 mm | 12 V → 26.31 mm |
More specifications
| Tunable White COB LED Strips; Model WS-COB-05-007; 3-wire CCT; 608 LED; 6+6 W/m ±10%; PCB options 5 mm; Supply / cut options: 12 V → 26.31 mm cut; Colors / CCT: 2700–6000K; Roll length: 5 m
|
| 608 LED3-wire CCTWS-COB-05-007 | 6+6 W/m ±10% | 5 mm | 24 V → 26.31 mm |
More specifications
| Tunable White COB LED Strips; Model WS-COB-05-007; 3-wire CCT; 608 LED; 6+6 W/m ±10%; PCB options 5 mm; Supply / cut options: 24 V → 26.31 mm cut; Colors / CCT: 2700–6000K; Roll length: 5 m
|
| 608 LED3-wire CCTWS-COB-05-008 | 6+6 W/m ±10% | 8 mm | 12 V → 13.16 mm |
More specifications
| Tunable White COB LED Strips; Model WS-COB-05-008; 3-wire CCT; 608 LED; 6+6 W/m ±10%; PCB options 8 mm; Supply / cut options: 12 V → 13.16 mm cut; Colors / CCT: 2700–6000K; Roll length: 5 m
|
| 608 LED3-wire CCTWS-COB-05-008 | 6+6 W/m ±10% | 8 mm | 24 V → 26.31 mm |
More specifications
| Tunable White COB LED Strips; Model WS-COB-05-008; 3-wire CCT; 608 LED; 6+6 W/m ±10%; PCB options 8 mm; Supply / cut options: 24 V → 26.31 mm cut; Colors / CCT: 2700–6000K; Roll length: 5 m
|
| 608 LED3-wire CCTWS-COB-05-006 | 7+7 W/m ±10% | 10 mm | 12 V → 26.31 mm24 V → 26.31 mm |
More specifications
| Tunable White COB LED Strips; Model WS-COB-05-006; 3-wire CCT; 608 LED; 7+7 W/m ±10%; PCB options 10 mm; Supply / cut options: 12 V → 26.31 mm cut; Colors / CCT: 2700–6000K; Roll length: 5 mTunable White COB LED Strips; Model WS-COB-05-006; 3-wire CCT; 608 LED; 7+7 W/m ±10%; PCB options 10 mm; Supply / cut options: 24 V → 26.31 mm cut; Colors / CCT: 2700–6000K; Roll length: 5 m
|
| 624 LED3-wire CCTWS-COB-05-006 | 7+7 W/m ±10% | 10 mm | 24 V → 19.26 mm |
More specifications
| Tunable White COB LED Strips; Model WS-COB-05-006; 3-wire CCT; 624 LED; 7+7 W/m ±10%; PCB options 10 mm; Supply / cut options: 24 V → 19.26 mm cut; Colors / CCT: 2700–6000K; Roll length: 10 m; Run conditions: 10 m, no voltage drop (624LED, 24V)
|
| 624 LED3-wire CCTWS-COB-05-008 | 7+7 W/m ±10% | 8 mm | 24 V → 19.26 mm |
More specifications
| Tunable White COB LED Strips; Model WS-COB-05-008; 3-wire CCT; 624 LED; 7+7 W/m ±10%; PCB options 8 mm; Supply / cut options: 24 V → 19.26 mm cut; Colors / CCT: 2700–6000K; Roll length: 10 m; Run conditions: 10 m, no voltage drop (624LED, 24V)
|
| 640 LED3-wire CCTWS-COB-05-006 | 5+5 W/m ±10% | 10 mm | 5 V → 12.5 mm |
More specifications
| Tunable White COB LED Strips; Model WS-COB-05-006; 3-wire CCT; 640 LED; 5+5 W/m ±10%; PCB options 10 mm; Supply / cut options: 5 V → 12.5 mm cut; Colors / CCT: 2600–6750K; Roll length: 5 m
|
| 640 LED3-wire CCTWS-COB-05-006 | 8+8 W/m ±10% | 10 mm | 12 V → 25 mm24 V → 25 mm |
More specifications
| Tunable White COB LED Strips; Model WS-COB-05-006; 3-wire CCT; 640 LED; 8+8 W/m ±10%; PCB options 10 mm; Supply / cut options: 12 V → 25 mm cut; Colors / CCT: 2600–6750K; Roll length: 5 mTunable White COB LED Strips; Model WS-COB-05-006; 3-wire CCT; 640 LED; 8+8 W/m ±10%; PCB options 10 mm; Supply / cut options: 24 V → 25 mm cut; Colors / CCT: 2600–6750K; Roll length: 5 m
|
